Outdoor LED full color display
LED outdoor full color display can be used in the outdoor brightness environment, such as airports, roads, culture and leisure square, commercial walking street, residential streets, commercial areas, stage and other public places. Because it has a variety of real-time signal playback their professional waterproof, dustproof, anti-static function, is often used to promote outdoor advertising, play an important news event or television programs.
Salient features:
A selection of high quality LED chip, strong anti-static, low attenuation, brightness, high wavelength stability;
2, advanced packaging equipment, quality assurance and life;
3, the room full color LED display RGB three-color LED lights can display 36bit color, real time and can simultaneously display various information, such as 2D or 3D animation, video, television and live on a variety of video information contents.
4, display long-term use can still maintain a perfect reproduction of the image quality and white balance and sufficient brightness.
5, high-precision LED-based optical design, so that far-field perspective diagram of three-color RGB LED perfect match to ensure that the screen picture from any angle can get perfect reproduction.
6, with the perspective of large, uniform color, low failure rate, easy to maintain.
7, the standard process to ensure that each row and column of the lamp at the same level, to ensure the stability of the screen is clear.
8 P65 in-class high-performance waterproof and dust!
|
|
|
参数
项目
|
P10
|
P12
|
P16
|
P20
|
P25
|
|
点间距
|
10毫米
|
12毫米
|
16毫米
|
20毫米
|
25毫米
|
|
LED封装形式
|
DIP 346
|
DIP 346
|
DIP 546
|
DIP 546
|
DIP 546
|
|
像素组成
|
1红1绿1蓝
|
2红1绿1蓝
|
2红1绿1蓝
|
2红1绿1蓝
|
2红1绿1蓝
|
|
模组尺寸
|
160毫米*160毫米
|
192毫米*96毫米
|
256毫米*128毫米
|
320毫米*160毫米
|
200毫米*200毫米
|
|
模组分辨率
|
16点*16点
|
16点*8点
|
16点*8点
|
16点*8点
|
8点*8点
|
|
箱体尺寸
|
960毫米*960毫米
|
768毫米*576毫米
|
1024毫米*768毫米
|
1280毫米*960毫米
|
800毫米*800毫米
|
|
箱体分辨率
|
96点*96点
|
64点*48点
|
64点*48点
|
64点*48点
|
64点*48点
|
|
物理密度
|
10000点/平米
|
6944点/平米
|
3906点/平米
|
2500点/平米
|
1600点/平米
|
|
亮度
|
5500坎德拉/平米
|
5500坎德拉/平米
|
6500坎德拉/平米
|
5500坎德拉/平米
|
5000坎德拉/平米
|
|
亮度调节
|
自动256级
|
自动256级
|
自动256级
|
自动256级
|
自动256级
|
|
最佳视距
|
10米-30米
|
12米-36米
|
16米-48米
|
20米-60米
|
25米-75米
|
|
水平视角
|
120度
|
120度
|
120度
|
120度
|
120度
|
|
垂直视角
|
50度
|
50度
|
50度
|
50度
|
50度
|
|
平均功耗
|
470瓦/平米
|
420瓦/平米
|
470瓦/平米
|
300瓦/平米
|
190瓦/平米
|
|
最大功耗
|
1170瓦/平米
|
1040瓦/平米
|
1170瓦/平米
|
750瓦/平米
|
480瓦/平米
|
|
驱动方式
|
恒流驱动
|
恒流驱动
|
恒流驱动
|
恒流驱动
|
恒流驱动
|
|
扫描方式
|
1/4扫
|
1/2扫
|
静态
|
静态
|
静态
|
|
平均无故障时间
|
10000小时
|
10000小时
|
10000小时
|
10000小时
|
10000小时
|
|
寿命
|
100000小时
|
100000小时
|
100000小时
|
100000小时
|
100000小时
|
|
帧频
|
60赫兹
|
60赫兹
|
60赫兹
|
60赫兹
|
60赫兹
|
|
刷新频率
|
≥ 380赫兹
|
≥ 380赫兹
|
≥ 380赫兹
|
≥ 380赫兹
|
≥380赫兹
|
|
工作温度范围
|
-20~+50度
|
-20~+50度
|
-20~+50度
|
-20~+50度
|
-20~+50度
|
|
输入电压
|
110~240伏特
|
110~240伏特
|
110~240伏特
|
110~240伏特
|
110~240伏特
|
|
IP等级
|
IP65/IP43
|
IP65/IP43
|
IP65/IP43
|
IP65/IP43
|
IP65/IP43
|
|
盲点率
|
﹤0.00001
|
﹤0.00001
|
﹤0.00001
|
﹤0.00001
|
﹤0.00001
|
|
控制距离
|
网线 100米 多模光纤 500米 单模光线 15千米
|
|
|
